Nuts and Bolts: Modular AI From the Ground Up transcript

[Music] great thanks Dave okay so let's get started so what is modular AI well it's a way to structure your AI architecture it's not a specific approach in fact you can take a modular approach and you can apply it to state machines behavior trees task networks whatever your decision-making structure is you can always make that more modular in general it emphasizes small easily reused modules and if you do a good job if you have a nice modular architecture it can be absolutely transformative to your development process it can allow you to do things like fast prototyping rapid iteration it's even going to increase the stability of your codebase so the nuts and bolts what we're going to talk about today in this session first off we're going to go through some of the academic underpinnings so we're going to present some of the theory and talk about how this stuff works next Kevin's going to come up and give some real specific implementation details code samples and really explain what this looks like and finally Troy Humphreys is going to come up and give an example from a from a ship game and show what this looks like in practice along with some general architecture discussion so this is going to be a bit of a slow burn but by the time we get going hopefully we've lit a nice fire and you're all going to be encouraged to go out and try to make your own architectures a little more modular so my name is Christopher dragger I'm in AI programmer at Ubisoft Toronto my background I'm actually sort of a software engineering engineer by training and it has a lot to say as a field about modular reuse this is something that people have been looking at for 20 years there's lots of theories there's lots of stuff in there what what we want to do and in fact what I did during my own PhD research I took a lot of those sort of basic software engineering principles and I applied them to modular AI in particular what I want to do in my portion of this session is really show how these first principles can allow you to develop techniques and create a good modularization for your own project in fact I'd like you to be able to think deeply about this topic so that when you're making choices about how to modularize things you can be working right from first principles and really understand the choices that you're making one of the biggest things here is understanding modular complexity itself right where does it come from what becomes harder and easier when you're doing modular approaches and importantly how to manage that and how to reduce it because that's what's going to make your modular ization successful so let's talk in general about complexity there's sort of breaks down into two main areas the first is essential complexity so this is the problem that you're trying to solve this is what you're looking at this is what you want to but this is what you want to do the other kind of complexity is accidental complexity these are problems created by us right when we say oh I want to put this in a special framework and run it on another thread and do this and then you know all those problems are aside from the core thing that you want to solve so a good solution is going to preserve that essential complexity and make it so you're just working on that and it's going to limit the growth of accidental so let's make this more specific now let's get to the topic at hand what drives modular complexity first first big driver is the module itself so the more complex your module is the more complex your modular solution is going to be the interface what do these modules look like from the outside how do we how do we work with these how do we understand them and finally what's the process for taking these modules and piecing them together how complex is that so for the remainder of my talk I'm going to go through each of those three areas and just talk about how complexity grows at each level and how we can manage it so the first area of the module and if there's one thing to take away from this from my portion I want it to be this good modules do not try to do too much the key to a good modular solution is to have small concise modules one of the biggest reasons is that a small module hours you to more easily understand what's going on it has a clear purpose if you go to reuse it you can be very clear and understanding this is what I'm reusing this is the functionality I'm getting so you want a good small module one of the big ways to accomplish this is by limiting the scope of what you try to accomplish within a module so one thing you want to do is try to separate cross-cutting concerns so that's a term from aspect oriented programming and the idea is that there might be a functionality that gets repeated across a whole bunch of modules right so an example let's say we have a melee combat module that selects a target and then our range combat module is also selecting a target and our flee modules deciding what target it wants to flee from right the answer here is should be pretty clear we need to take out that target selection and actually put it in its own module right so we need a target selection module so we separate this sort of functional concerns target selection is its own thing melee combat is its own thing that just attacks whatever target its given and we make all these modules sort of work from you know communicating with that other target selection module what's great now is that when you do something like that you can then say you know what I want to reuse just the target selection module and you have that clean separation another thing you want to do is control the size of your modules so this is just a more general comment here we need to do this stuff that we already do as AI programmers so traditional abstraction techniques everything that we should already know and love if you're working with a state machine for instance you want to use hierarchical approaches if you have a lot of events going through your system you want submitting approaches to help manage your different modules if you're working with behavior trees use parallelism where appropriate you know all these kind of things that we do it becomes doubly important in modular approaches so that we can control the size one thing that we don't think about as much as AI programmers is a well-defined semantics so what did I mean by this well your AI logic should operate in an understandable and well-defined fashion normally when we program things we can often think about you know how is this piece supposed to work how does it fit into the rest of my AI we can kind of solve that problem it works but if you can't communicate that then you're going to fall apart to the next step which is maybe moving that module between engines or moving it to a different game and I'll give an example that really clarifies this so let's say we have a super simple state machine we have a combat state it receives a flee event we transition over to the flee behavior ok now let's add some hierarchy now in the combat state you can see I've added this fire sub state and it actually has a transition on the flee event as well so if we're in that fleece state or sorry if we're in that fire state and we flee what do we do right your implementation is going to make some choice do I follow the inner transition or the outer one I'm not I'm not here to talk about the right way to do state machines the important thing is that when you go to reuse this wherever you put this we have to make the same choice right our new context our new engine it has to make the same choice so we have to communicate what our exactly how these things work what our semantics are this example also applies to custom decorator nodes and behavior trees if we want to reuse those we need to make sure that they're functioning correctly in the new context so moving on I'm gonna talk about the modular interface now what does it do well it should communicate the context for the module so the expectation of that module what is it trying to get from the rest of the AI what is it providing to the AI we should be able to understand that from the interface if you've done a good job making small concise modules then we should have a clear easy to understand interface the big step here is that we're raising the level of abstraction now one when we have a good interface and we can work from it we don't have to worry about how exactly that module operates anymore you can just work directly at that interface level which means you can focus on the essential problem of connecting our modules and not worry about sort of all the accidental stuff of how that behavior works so I've said context a lot what do I mean by that state machines for instance they're an event-based formalism I'm just going to work through this example here generally they you tend to think about input events they might be generated by other parts of the system they would get consumed by our module they might also generate output events that would go to other parts of the system so then our interface should tell us what exactly this module is expecting so I'm just going to build one out here this is for a enemy position tracker module we might want to include some metadata so a description of the module this modules parameterize that control the type of the I can control the type of the enemy entity that I want to track and that's about it we don't really need to worry about the functionality now as input it's going to be looking for a couple specific events the first would be an enemy spotted event the second would be an enemy lost so basically this is telling it when to start and stop tracking we don't really need to worry about what it's doing to sort of maintain its own list that functionality it doesn't really matter those events are going to come from some other part of the system and we'll be able to use them now as output we can then generate this enemy position changed event so maybe you have a cover module for instance it receives this and it decides whether or not it needs to reevaluate cover so now we can see how we would take this position tracker and sort of situate it within a context moving on a second example here behavior trees so these are a bit different in that they're primarily data-driven what we want to think about here is sort of how our nodes are communicating with the rest of the behavior tree or the rest of your a eye architecture well primarily they're going to be reading input off the blackboard to you know understand the context and they're going to be writing output to that blackboard so when you think about building an interface here we want to capture that data but a specific warning that's not the full story for behavior trees the reason is that there can be a lot of different things going on especially in newer behavior trees or we can have nodes that instead of just returning success or failure they can also run over multiple frames well the question there becomes how do we interrupt it where does that interruption come from in fact in other situations you can even have the tree structure itself which is providing this interrupt so somehow we have to deal with this I'm going to give an example this is something that I've seen in production code we have a parallel branch here it goes to the top there and we get a infinitely repeating decorator this is just checking a conditional when that conditional becomes false this branch is going to fail out and we're going to move on to do something else but at the same time we also have another infinitely repeating decorator and it's going to be going through and performing some behavior at the bottom now say I really want that behavior at the bottom I want to reuse that I want to put it somewhere else so then I trimmed that and move it and move it away well what's gonna happen is that I'm gonna introduce a huge bug into my new system because that bottom branch it doesn't know how to stop itself that was happening in the top branch right so I have this sort of functionality that's now split and there's a dependence between these two branches if I want to get that to work correctly I'm gonna need to reuse the whole thing right I need to include that that stopped case so these are the kind of things that you need to look out for when you're specifically trying to use behavior trees so I'm gonna move on to the the third and final area which is just an overview of integration so this is the process that we actually use to fit these modules together if you've done a good job in creating concise modules clear interfaces then integrations should be straightforward right if you've made mistakes if you have big complicated modules this part is going to be really hard so a lot of your area errors are going to become apparent here essentially what we're trying to do is connect the output from one module to the input in another right it's a fairly straightforward thing and we should be able to focus explicitly on that everything else is accidental complexity so you really want to try and limit anything that detracts from that core problem the complexity of this we can manage it a lot by making sure that module connections are derived will solely from the interface so as programmers we need to treat this almost like an API right and in fact the other thing this does is that this preserves modular encapsulation this is just like object-oriented programming now where we want to make sure we're working our high-level interface and we're not creating spaghetti code and digging inside so for all the same reasons that you know encapsulation is good a normal code it's just as good in modular AI so if you do this consistently and if you do it well you can start to add tool support right and this can tell you things like I have an output from one module that's not consumed anywhere or I have this data that I'm trying to read off the blackboard that no one else writes you can start to see those errors really quickly and really easily and then that will teach you okay I need to add this module or I need to have something contributing that data one last thing I want to talk about here is module coupling the goal here is to create loosely coupled modules so these are when you have a loosely coupled system a missing module impaired impairs only that behavior what do I mean by that well if you think about our target selection example earlier where we had our mealy module let's say we take that target selection module and we pull it out so there's now nothing in your AI that selects targets well I would want my mealy module just to say oh I don't have a target I'm not gonna do anything but other functionality within that AI so a wander behavior interacting with environmental objects all of that should still be able to happen right if you have this approach then you can really quickly and easily start to add modules to do fast prototyping you can change your composition to rapidly iterate on this the alternative is a tightly coupled module so this is where maybe one module is you know actually calling a function that's written in another one if you pull one module out you're gonna have a compilation failure maybe we have our mealy module with no target it still tries to run in the crashes you know these kind of things you don't want that that's what you need to try to avoid everything should be as loosely coupled as possible when you have problems like this a lot of times it's caused by broken encapsulation when you're not working through the interface or you could have a modular concern some kind of functionality that's spread across multiple modules special cases in general are really dangerous I'm just going to go through one straightforward example here let's say we have a sensor module and every time our AI spots a new enemy it creates this new enemy spotted event and then we have a reaction module and every time it receives that event it's going to play in animation it's going to play some reaction but we actually run this and we find oh wait i'm seeing that reaction way way way too often i mean i need to turn that down so i want to add some hysteresis I'm gonna make my event system all the events are going through there so I'm just gonna add a filter it's gonna cap generation of these new enemy spotted events no more than one per minute so now everything looks good but then I go to reuse it and I put my sensor and my reaction module in a new context and that same bug is going to appear again right because I lost that filtering bit and there's no obvious way about how this should work right I don't have a filtering module I haven't created a filtered reaction or anything like that so these kind of things they're kind of dangerous a lot of times are because of broken module encapsulation here it's a functionality that's mixed across a few things but let's say we do all this right we're going to get a nice payoff the first is fast prototyping right we can now quickly and easily add our modules we can fine-tune we can parameterize these module interfaces so that we can say this specific module in this AI is going to have this set of parameters and this other ones going to be slightly different so we don't lose that ability to polish our AI and probably the biggest thing here is that the development process overall it's gonna be better right we can reuse existing behavior we can get to a baseline very quickly and that means the bulk of our development time we can spend innovating and we can spend creating new behaviors so that you can really try to push the boundary of what your AI can do so I'm just going to summarize a good modular approach it's gonna check all these boxes we're going to use small modules that do a nice job separating functional concerns we're gonna operate with a well-defined semantics so we can always understand how this thing should run it has a clear interface so that people can understand how to connect it all of our connections are going to respect modular encapsulation and we're going to use a loose coupling approach so that we can really quickly and easily swap modules and swap compositions so if you've done all that if you checked all those boxes you're off to a great start thank you all right there we go so I'm Kevin dill I wanted to start with a little bit of motivation from my point of view some of what makes my floor AI so exciting to me so as I was thinking about this talk and I was thinking about why it works and what makes it powerful I remember to talk to Chris Hector gave back in 2008 called structure versus style and he basically made the case that a lot of problems that we have made great progress on have this sort of structure versus style decomposition and Graphix is one example where you get the texture map triangle which is your structure and then your style is all the ways you can use textures and triangles and you get graphics right you get scenes and beauty and and awesomeness and as a result of this decomposition graphics he argues has made huge bounding leaps over the last 30 years and AI has not so his suggestion was part of the reason that AI has not made these leaps is that we don't have a structure versus style decomposition for AI so there was a lot of discussion back and forth in the community some people said Chris's are in cracks when people said Chris is brilliant but I don't know what the structure versus tile decomposition is I'd like to suggest that modular AI gives us the opportunity to have the start of this sort of structure versus style decomposition so I you know and I think that's why it allows us to work so much quicker and hopefully will continue to progress forward for us so I should also mention that everything that I talk about is going to be pulled out of ideas from the game AI architecture the fact that it's game AI isn't interesting to this community but I work for our military simulation company Lockheed Martin so that's an important distinction to them as opposed to drew you know traditional more academic kinds of AI this architecture has been used across probably six very different projects to solve different kinds of AI problems right character versus flight simulators versus other stuff it's been integrated into a bunch of different engines at this point and something important to mention is I set out of course to create an architecture I could reuse but I never was able to just sit down and build the architecture ever all the work that I've done on this architecture has been done in the context of working on a project and by just making sure that I keep my architecture deep decoupled from the simulation so I can carry it with me or from the game so I can carry it with me from project to project I've got all of this you know now large reusable code base that's really powerful so what the agenda for my portion of the talk I'm going to talk about what I think my jewelry is of course Chris just gave us a bunch of that I'm going to talk about some common conceptual abstractions and you know what that means by the time I get there I'm gonna give it just a brief example of a small portion of a sniper character I'm gonna give a few implementation details as time permits and then I'll leave you with some parting thoughts so the big idea behind modular behind modular architectures is that I want to be working at the right level of granularity I want to be using sort of bite-sized pieces and by bite-size that you know Kristen well they can't be too big and that's definitely true if they're too big then I can't tune them and customize them to the needs of this specific instance where I'm sticking them in but they also can't be too small and lines of C++ code are much too small as I'm defining behavior I don't want to be thinking about implementation details about how do I get the position or should I use distance or distance squared that kind of stuff I don't want to be worried about that when I'm defining behavior that's just as distracting each piece that I plug in should ideally be sort of a single human concept so something like how far away is here how long have I been doing this or do I have any grenades left right but it doesn't have to be just the decision-making part it could also be the actions right I want to move over there I want to shoot at that guy right that kind of stuff so to get these bite-sized pieces we start with what I've been calling conceptual abstractions conceptual abstractions are the different types of pieces that we might plan together so for example a consideration is one conceptual abstraction considerations evaluate some aspects of the situation and then I combine the considerations together to get an overall decision actions are a different conceptual abstraction right actions are the things that I'm going to do as a result of some decision that I've made once I've got my conceptual abstractions then I start to build modular components these are implementations of the different abstractions so a distance consideration measures the distance between two points and gives some evaluation of that a move action handles moving from one position to or moving to some specific distant position another thing just to keep in mind is you know no surprise this is data-driven right so my implementation is all the C++ side and then I've got a configuration which I'll often call my behavior specification right where I'm defining the behavior for a particular character and I'm plugging in these modular components to create decision-making algorithms so running through a few common conceptual abstractions the first one to talk about is the reasoner the reasoner is the big thing that makes decisions so it could be any decision making architecture that you want it could be utility based it could be rule based it could be a finite state machine it could just be a sequence of actions that are always run in the same order no matter you know no considerations are used right if you want some scripted behavior or something like that and different reasoner's make sense in different places right even if I am doing you know fighting AI and a shooting game right I might still have some sequences where you know I aim fire and fire right that's just a sequence I don't need to make any decisions in there so I'm gonna stick in a sequence reasoner just to do that one little bit considerations evaluate a single aspect of the current situation again there are lots of different kinds of considerations right a distance consideration and execution history consideration looks at how long I've been doing something or how long since I last did it on the picker is a particularly interesting consideration it goes through all of the entities that I know about and it can apply some filters or it can actually use it a reason or internally to pick among all of the entities so for instance if I want to pick a target to shoot at I could have a picker consideration that picks its heart based on how far away it is how much cover it has it been marked as an officer because if I'm a sniper I prefer to shoot at officers is it firing at me is it looking at me whatever else I want to put into that decision I put inside the picker and then the picker just handles picking the one entity and scoring based on whether it finds something or not and it also by the way writes that entity on the blackboard so that I can reuse it when I want to shoot at it or chase it or run away from it or whatever I'm gonna do actions are the things that I'm actually gonna do once an option gets selected so things like moving or firing a weapon again an interesting action is the sub reason or action the sub reason interaction contains another reason er so this is how I get my hierarchy right I have a high level decision that picks I want it to shoot at enemies and then a lower level reason or inside of there that handles the aim fire aspects perhaps targets are how I specify positions or entities I need to use those two things all over the place right a distance consideration measures the distance between two targets what are the targets well they could be anything right it could be me right the character that's under control it could be a named entity may be the name of the entity is player right I want to measure the distance between myself and the player it could be a fixed position it could be the camera it could be an entity that's been written to the blackboard right lots of different kinds of targets can just be plugged in you know not only in the distance consideration but in the move action or the fire action or anywhere that I need that sort of thing weight functions are a good example of the kind of cross-cutting concerns that Chris was talking about so in considerations I found a lot of considerations come down to they have a floating-point number right a distance consideration is a number right the the number of the distance in meters execution history consideration also gives me a number it's the amount of times and something happened so I want a standard way to convert from a number to whatever the output of my consideration is and I'm not going to tell you what that should be today because there's not time but the considerations that I use return three different values so the job of the weight function is to in some standard way convert from a floating-point number or an integer or recently I've added the ability to have entities so you can pass an end to a weight function and it returns an evaluation on the basis of that to the output of the consideration so the boolean weight function for instance just says it treats it as a boolean right so for instance that picker is going to return the number of entities that it finds typically it uses a boolean weight function which says if I find zero entities then return this set of weight values and if I find one or more entities then use this other set of weight values right did I find it or not the distance consideration could use something like a float sequence for instance if I want to say I do one set of things if the distance is between 0 and 50 another if it's between 50 and 100 and a third if it's over a hundred right the float sequence breaks the float in two regions and then it returns a different set of weight functions for each regions a simple curve is the kind of thing that you're dave mark talked about all the time where you want to take the number and maybe apply some sort of formula to it to turn it into an s-shaped curved or a parabola and then you're going to take that maybe you want to normalize it you're going to stick it into one of the weight values that you're gonna return the simple curve weight function handles all of that kind of logic and there are other special purpose weight functions that get used in other places the last thing I'll mention is a region a region is just a standard way to define some space in the world right it could be a spawnvolume it could be for my sniper if he's firing down into a marketplace I could define the kill zone for him and you know I might represent that as a circle or a rectangle or a polygon in the latest work that I've been doing on flight simulators quite often the military has a line and when an aircraft crosses the line that changes their behavior they change to a different stage of engagement right so it could be here's a line in the sand and in one side is one region and one side the other side is the other right regions just have to be able to know if you're in the region or not and maybe if you want to do something like a random wander it's used to be useful to be able to pick a random position inside of the region so moving on to the sniper example imagine that we have a sniper character and this is drawn from a real character that we did build although it's not exactly out of that character and the sniper does a bunch of different things right he can move away he can whatever other things he needs to do but one of the most important things he's going to do is he's going to be in this sort of sniping behavior where periodically every minute or two this is military simulation now not games so every minute or two he wants to take a shot at the enemy in games it would probably be more often but also this is military simulation so unlike most game characters our sniper wants to live so if he doesn't have a line of retreat he's not going to take a shot right and that's pretty common for real-world snipers if they don't think they have a way to get away then they're not going to engage hopefully there a way to plug in do you know you don't see why sorry I just got a battery warning all right and also with each additional shot he wants to decrease the priority of taking further shots because every shot increases the risk that the enemy will figure out where he is so he's gonna have an option somewhere in some reason or it's probably gonna be a utility based reasoner that's picking the high level thing he's gonna do that is the take a shot option and that option is going to have some considerations on it that tell us when we should do this thing and then some actions that say what we should do in the case that it gets picked after dodging we this is great extra challenge I really know I blocked I probably shouldn't take any shots so the first consideration we're gonna have is an execution history consideration the job of this consideration is to make sure that we only take a shot every minute or two so execution history consideration can be configured in a couple of different ways in this case we're giving it a stopped weight function which is the weight function that gets used when the option is not currently running so this consideration is going to do its work when we're not in the process of taking a shot and that execution history consideration is going to just pass the amount of time since we were last executing into this wave function the weight function is a float sequence so it's going to divide that floating point possible values into in this case two areas one that's less than some random amount between 6000 you guys can't argue you're not gonna be able to see the mouse 60 and 120 and in the case that it's in between 773 is the number of the spectra say it's less than 73 seconds then the weight values that I'm gonna return are to set Vito to true and Vito just says I don't care what any other consideration says you cannot do this right now right it's an absolute veto otherwise if it's over 73 seconds then we're gonna set Vito to false which is effectively and no up it says you know what I don't care right ask the other considerations do it if you want it's up to you the next consideration we're gonna have is going to be a picker consideration this one is defined globally partly because there's not space on the slide but also because this is picking a target and we likely would have other behaviors that would also want to pick a target to shoot at in different situations and the picker is gonna do the kinds of stuff I said before right it's gonna look at the targets check that they're in the marketplace check the distance to them check how much cover they have look for ones that it knows to be an officer if it happens to know that and use all of those values to pick the best target to shoot at and then it's going to use a boolean weight function to say if I've got something to shoot at then set Vito to false otherwise set Vito to true if I don't have anything to shoot at then I can't shoot and it's also going to write that target to the blackboard for use later the third consideration is a another picker that's defined globally the names on these by the way so Global's are defined somewhere else and they're given a name and the name just tells me which global to stick in this one is going to use a region to define my area of retreat and it's going to use a picker just to check if there are any entities in that area even wait well cheat and use all entities rather than just using known entities in order to get the behavior to do what I really want and avoid it looking stupid when the when the player goes well you should have known about that entity but he didn't and last but not least I'm gonna use an integer variable consideration this just looks on the blackboard for variable name num shots which should be an integer and then it's going to pass that integer into a basic curve the basic curve is going to transform that integer into something that decreases the priority of this option with each as they as the number of shots increases right so that's how I try and decrease priority with each successive shot if this option gets selected it's going to do things two things first it's going to update that integer variable num shot so it's going to incur in this case the update we're gonna do is an increment write this action could also just set it to a static value but that's not what we want to do here so this is how we keep track of how many shots we fired each time this option gets selected this action increments the number of shots that have been fired and I also have a global action because other people might want to do the same thing that's going to fire at the target that we wrote to the blackboard and that probably has some more logic inside of it that handles going through whatever sequence of fire actions making sure I'm in the right animation and that sort of thing so what does all of this buy me the most important thing is that as I'm doing my work right as I'm specifying behavior I'm thinking at the appropriate level of abstraction right not too big not too small definitely not implementation details so if you look at this execution history consideration for instance I enter about six values right its execution history it's a float sequence the minimum and maximum values and what to set the vetos true and that expands out to probably a couple hundred lines of code and it's not just the obvious you know keeping track of when the last time I did it is but also little things like getting that random number and making sure that that random number is updated at appropriate time so each time I take a shot I want to pick a new random number for the next shot but I don't want to pick that every frame right because then it's quickly just going to be 60 because I'm picking it you know over and over as it gets smaller or sooner or later it's gonna be small enough that I fire so that's not hard to do but it's a little bit tricky you can introduce a bug there right so you'd rather implement at once and then reuse it the other thing to notice is that the values that I'm specifying are the relevant ones if I were describing to you when the sniper takes a shot like I just did the things that I would tell you are things like he's gonna take a shot every minute or two right so what am i putting in here that you know the time since the last shot needs to be between one and two minutes right that's exactly the same values that I gave it that I tell you in my human description of what I'm doing this also allows me to have really broadly use both of the code itself right this execution history consideration gets used lots of places this weight function gets used even more places but also the XML right if there's something that gets reused a lot then I can define it globally and then just plug it in since I reusing something right I only have to implement it once the time it takes to implement is a cost I pay one time instead of paying every time I need to do it I also get fewer bugs right every time I write code there's the chance of introducing a bug if I don't need to write some code I'm not going to introduce a bug and my code becomes much more mature it's much better tested because it's being executed lots of different ways so it's not only more tested but better tested right it's tested lots of ways and it also becomes more feature-rich as I add new features and new capabilities like the ability to pick that random amount of time instead of just specifying a fixed amount of time now I have that capability and I can reuse it going forward and if I wanted it to be an exact amount of time by the way in the XML I would just put exact equals and then I would put the exact time so the bottom line is the developer flow right the developers sort of in this flow where he's thinking about the concepts that he cares about or she cares about it in the specification that they're defining not about implementation details in the low-level stuff that's just a distraction so a few implementation details obviously the biggest thing is polymorphism right no surprises here we're going to have a base class for each conceptual abstraction which defines the interface and then everybody else is doing is just going to interact with a consideration or an action on the basis of those base classes you probably eyes probably saw I put the simplified versions of those interfaces and those slides should you want to go back and find them this lets me decouple the interface from the implementation right so nobody needs to know that this is a distance consideration or how the distance consideration is implemented this also makes it possible for me to inject code from the simulation or from the game up into the the AI architecture without the AI architecture knowing anything about that code so the move action for instance is going to be game specific right how you go about moving a character around in game and deal with physics and collision and planning and all of that that's going to be game specific the AI doesn't need to know any of those implementation details it just knows it has a move action it's supposed to give the move action the set of values you have to have factories which handle reading the XML and then creating all of the objects inside of it so you'll have a consideration factory for instance which pulls the type value off of each consideration and then creates an object of the appropriate type what you pass to the the factory is not only the xml mode but also some contextual data and where the blackboard is what entity you belong to if you're underneath an option what option you belong to because the execution history consideration for instance needs to know which option it belongs to one nice thing about the factories that we have in Gaia because we want to be able to reuse it across multiple projects is they have this notion of constructors so constructor is just an object that knows how to create some subset of that conceptual abstraction so a consideration constructor knows how to create a bunch of different kinds of considerations the factory can have multiple constructors and it just asks each one do you know how to create this okay you don't next guy do you know how to create this until it finds one that knows how to create the object that it means this means that my simulation or my game can pass a factory into the AI architecture so this is how we inject code into the AI last thing they'll say about factories it's really powerful to have a single implementation right I decided some time ago the duplicate code was of the devil and I was going to do everything I can to get duplicate code out and so far I had never regretted that decision so I'm gonna have lots of different factories one for considerations one for regions one for weight functions I want to make sure that I have one set of code that they all execute so that I don't have this situation where I have this one factory that's a little funky works in a slightly different way and I have to remember how it gets used or I have a bug in one factory and I forget to fix it and the others or you know that kind of stuff I don't want to worry about that the other nice thing is if I do it this way where I just have a macro that creates the factory for me then when I come up with some new kind of conceptual abstraction and that happens more often than you might think I just have to call the macro and all the infrastructure is there it's all created for me so this is roughly what that macro looks like for the factories I use macros much more widely than this Matt you know macros are a pain to debug figure out how to get your compiler to expand the macro out for you so that when you need to debug it you can do that as I said earlier I don't have time to talk about how we combine considerations but there's been a bunch of good talks on this I gave a talk yesterday on the trigger system which used a very simple boolean approach to combining considerations Mike and Mike Lewis and Dave marked last year give a fantastic talk in which they talked about how they combined considerations in their architecture I gave a talk with Dave a couple years ago where I presented and do a utility based approach I really recommend the third the duel utility based approach it's straightforward to implement right it's not hard to get it up and running it's extremely flexible right it lets you do either really hardcore utility based AI stuff or really simple yes-or-no stuff and you saw some examples of both of those in the sniper and it's probably choose trying to say it completely avoids the sort of combinatory problems then Mike and Dave have because it's utility based so of course it doesn't but they had a problem where the more considerations you have the more it forced the values down when they multiplied them together and the dual utility based approach gives you some different options for how you combine things to try and work around that in different ways but you don't have to pick one way right so a consideration set is the thing that wraps a bunch of considerations and combines them together it's all in data in the data you can have a flag that says combined in some different way or you could have a different you could make a consideration set of conceptual abstraction and have different consideration sets that use different types of considerations if that's the thing that you feel like you need to do what I've done is I have a few flags that change the way I combine the but I only have the one kind of the one kind of weight value that I use everywhere so final thoughts remember the what does this buy me right the important thing is it lets me think at the right level of abstraction it keeps me in that good flow so that I can implement much more quickly I can iterate much more quickly I've seen modular approaches pay off on projects that are three months long right when we did the boss AI for Ironman we used the modular architecture and we were very quickly getting to the point where you know it was a three month project and I don't think we could have hit it if we hadn't had that ability to iterate so quickly and it also you get much more reuse so your code is better tested you have fewer bugs and your code becomes more feature-rich and it's easier to carry it with you to future projects you don't have to throw out your architecture and start over look for opportunities to do something in a modular way in your architecture weapons selection and target selection are common cases of plugging in some considerations in Red Dead I was assigned to build the attention system that got characters looking around in town and I decided even after Ironman not to do it modular lis because I thought it was just going to be very simple and we got eaten to death by special cases you know I thought it was just gonna be picked something nearby at random and look at it for a little while and then pick something that's not in the same direction and look at that but there was they well when this said you know when the player does this then you should look at them but if this event happens then you should look at that but not if this other thing happens then do that right and so all of those special cases anus to death and I really wish I could go back in time that I couldn't just build it in a modular way in the end Red Dead shipped with a pretty cool attention system but it was a lot more work than it could have been and if you're gonna do one thing start with considerations considerations are a really really powerful way to layout to decisions last thing very quickly the Mars game is out there I mentioned this yesterday it's open source so if you want to see code examples of how all this works together you can go grab the code from github it's a simpler modular system but it has all of the big ideas in it so that's it for me I'll try [Applause] all right how's it going my name is Troy Humphries I'm the lead AI programmer at Turtle Rock Studios I'm also going to talk about modular AI systems so why this talk well I think game AI architectures are pretty modular you know like we have behavior trees finite state machines planners all these things are modular systems and modular systems come with a lot of benefits right we get code reuse flexibility ease of character creation and so on and on evolve on evolve we used a beber tree but it wasn't giving us the modularity you want we wanted it was still hard to get the AI out the door the BT word fine but we simply weren't getting all the games we should have been getting from modular system so we decided to fix this and we decided to focus on two things first was figuring out why the modular baby tree that we were using wasn't giving us all the benefits that we wanted and we needed to do this without breaking any of the legacy characters in systems because we were still developing a live game we still DLC characters coming down the pipe we couldn't mess any of that stuff up so how do you feel that modular right so well how about a little example to help illustrate this point given else okay that's better so in our example we had before stroll and he's going to do a very simple attack called the tree trunk tornado right he uplifts a tree and spins around knocking everybody back I think everyone can visualize how that would look in their minds but let's get into some details here first he should only do this attack if he's currently surrounded by enemies if he is surrounded by enemies he's gonna do a point-blank and we knock back attack and after completion he's going to be tired we want to set some kind of state of tiredness to be used in some other behavior later down the line so we can simply just make a node in the behavior tree to handle this stuff right on start we can check to see if there's enough enemies if not we can fill out if so we can go on and go ahead and play the animated attack part which is triggering anim Chin's playing sounds damage boxes and things like that and on completion we can set some stage and like the blackboard for tired which we could use later and I think this is a perfectly reasonable implementation right this could and it's it is modular I can find another situations my behavior tree where I might want to use the same attack but we all know what happens next right the designer comes to you and says alright I want to tornado in a completely different situation maybe in a combo or getting up from a knockdown or something like that and all of a sudden that is surrounded check is causing trouble right because he doesn't care in those situations if he's surrounded or not sometimes the designer might want the tornado to trigger without setting patrol tired right you might want to be able to use it in different situations and all the sudden our Marge nice little modular attack isn't modular anymore so I'm sure you've seen similar examples and some formula or another and a lot of code bases we had a lot of this and evolve it was getting as kind of a death by a thousand cuts type of thing so I started thinking a lot about what had worked on systems I using the past I've gotten lucky I've gotten to work with ship games with her called foreign state machines I've we've shipped games with go p-- HTN and behavior trees and every time i think about all those systems they all had one thing in common when they worked really well they had a really good separation of responsibilities so i think the separation responsibilities is something we can all get behind we talk about good abstractions all the time and software engineering but i want to talk about 3a i centric responsibilities that i think are crucial to having a good modular system so let's user a tree trunk tornado example to help illustrate these three areas the first responsibility is sensing this is where we translate information about the game into something that i can understand and our example it's the is surrounded question breaking the sensing logic out of the tornado allows us to ask the same question about different targets which can be useful for other behaviors it also allows us to fire off the tornado if the trolls surround it or not which helped solve the earlier problems we had with our designer the next responsibility is acting this is where we see the AI actually do something in our example it's the animated action part of our attack it's a logic that starts the animations plays effect sounds triggers damage zones and now that are sensing logic is out of the attack we could use that same animated attack action with different data to do all kinds of different attacks the final responsibility is deciding and when we think of most AI systems this is where they would live our financial state machines planners and for us it's our behavior tree this is going to be the spot where we assemble all the other responsibilities into a reasoning character we do we do this by defining the why the character will do the things it does and how we'll react to them in our example we would use the animated attack action to do our tornado then we could decorate that action with a condition using the sensing data that we got from our is surrounded since sensing logic and lastly we can add an effect that would set the state on successful completion attack this would satisfy the making the troll tired part so betting a lot of you are probably thinking mmm this sounds a little familiar and you'd be right this is sense plan act but I don't want you to get hung up on the planning part I'm not trying to push planners on you I'll save that for another talk but I wanted to talk about how this could be a guide for better modularity regardless of what architecture you're using so let's dive into these areas more detail with some guidelines and kind of what we did with our refactor and evolve but first let's talk about something that I think helps make all these areas work in concert something called the world state so the rule states kind of like your glue if the game state is the actual data in your game the rule state is a simplified representation of that state as far as the character is concerned I'm sure you all different flavors of this blackboard's context if using planners would be a world state so some guidelines for setting this stuff up oh the rule states really just a big block of data it should be easy to write - easy to read from so some guidelines every character should be able to have their own set right different characters need different information to be able to make decisions keep the structure very simple right fast access faster right to an array is a perfectly acceptable world state for evolve we split this concept into two things now first we use a blackboard as used to represent the simplest enumeration of the world state required for the decision system to make decisions let's take the characters health for example we could use the characters help percentage as a value in our world state but zero to a hundred percent is a lot of state right we aren't going to be making decisions on 101 different states if we're using an INT if it's a float it's even more right but if what we would like to make decisions on as if the characters wounded if he's healthy if he's dying this is the type of say that we want to swarm a blackboard because that's the type of data we want to make decisions with the second part of our world state something we called the white board and I was very clever but this is where we put all of our rich data in our world stage right all the extra data that isn't used to make decisions but is used to run behaviors so this might be like the best cover locations the biggest threats and so on so let's get the sensing this is where we translate the game state into world state this doesn't just mean hearing and vision and things like that this can be as simple as taking that health percentage and translating it into the healthy enumeration or as complexes picking good cover locations some guidelines that help you go modular and atomic you want to keep these nice and small sensor shouldn't know about each other no sensitive sensor dependencies you use the world state to communicate if you need to characters should be able to have their own sets of sensors right if you're gonna have different world states they're gonna need different sensors to fill that world state translating game state in total speech can be very expensive right so we want to be able to bend throttle defer our work anything we can do to handle that workload another thing that you should keep in mind is to keep sensing out of your deciding loop if it's possible we just said it's expensive we want to be able to quickly make decisions to try to keep that stuff out for evolve we ended up making a new sensor manager to give us a formal and really easy place to do our sensing work it allows us to install sensors character type and allow sensors to have a different max sale time per character type meaning this is how long the sensor can go without getting an update this is great because it shows the importance of that sensor to that character type so as an example imagine you have a line of sight sensor and two characters arranged in melee character well the range character is gonna need a higher refresh rate because he needs to constantly check to see if you can hit people from range right the melee guy not so much he just needs to know the general location of where the guy is and that can be updated and slow because he just gonna run up and smack you in the face anyway and to make it even simpler this time the way you started by the time is a simple enumeration something like every frame a lot often sometimes never why have our programmers come up with a perfect floating-point time to do a refresh rate when we're just really just looking for what that sensors importance is to the character using it so our manager will just burn through as many tenders as they can and it's a lot of time at favorite sensors that are getting closer to their stale time and since we use an enumeration for time we can tune those different frequencies behind the scenes without breaking the characters types needs we could also play with these two if we want to do alibiing and stuff like that so acting acting is what makes up what the AI actually does right this is what the player is going to see these are your attacks or reloads your interactions your tornados things like that different systems will have different terms for this right HTN uses operators dope users actions behavior she's use nodes states are in finite state machines some guidelines to keep in mind operations should be agnostic to the reason they're being done we saw this with a tornado example if the reasons baked in it's going to be harder to use that tornado elsewhere if that is surrounded check is in there the only conditions that should be baked in are what's actually needed for that action from run of that operation to run so let's say we had a fire gun operation you need the gun to be able to fire it right so that's an OK considering our condition to put in their operations should be agnostic to the world state at reference is let's say the troll had a boulder throw right the bowl to throw operation shouldn't care if he's throwing it and then me a building or some other object it just needs a location or to throw that Boulder operation shouldn't try to do more than one thing right there just the more they do the harder it's going to be to be able to find situations where you can reuse that operation operations shouldn't change the world state right going back to our tornado example there were going to be times that you want to be able to do a tornado without the troll getting tired right so we want to keep that real state change out of your acting and why do it right if are deciding logic gives us a nice way to do this operation why hide the state change from the person looking at your decision logic or your decision structure so for evolve our acting as the number of BT nodes points which okay and what we ended up doing was refactoring a whole bunch of them ripping out the sensing logic and deciding logic out of those acting nodes and if we didn't do that we just made new nodes that just really focus on acting this gave us smaller and simpler building blocks to work with going forward with our new characters the last responsibility is deciding right this is where we make decisions or better put this is where we translate world state into action right it's the behavior systems that we use it's HGN go behavior trees finite state machines kind of right this is typically the structural part of those systems right it's the tree structure of behavior trees in HTN it's the grass structure of our finite state machines go for the priorities of a utility based system some guidelines to keep in mind when you're building your deciding logic the something should be fast that's hard to argue but I mean if you want to be able to react to changes in a rural state as soon as possible so trying to keep all the heavy lifting outside of your decision system deciding should also allow us to define the conditions required to execute operations and the effects on succeeding those operations it also should be fast to edit and I don't mean you need an editor right you just need some clear way of defining your structures and you're deciding logic for home we use a behavior tree described in build Merrill's game AI Pro article it's now free on the website it's a great article you should definitely check it out luckily we didn't need to change this at all I just worked we'd have to change a lot of the nodes and sensing logic so something I haven't talked about is our blueprints evolved uses blueprints as to have one location where they can set up a character this is the integration step that Chris was talking about earlier here we load our designer tunable data we define our blackboards and install our whiteboards we installed the other different components that make up that character their sensors their behavior trees things like that and as we install our sensors and build our BTS this is where we're going to do all our wire work right we're gonna tell the sensors where to dump their data and the blackboard right we're gonna tell our decision tree what blackboard variables or behaviors we what blackboard variables to look at this was an incredibly important step to us like this is where we were able to build our new system side by side our own system if the a I had was a blueprint AI we had a whole different initialization call stack to run through if they weren't and went through the old legacy systems and once we had this set up we could quickly start using the new systems without worrying about breaking any of our legacy code so let's talk about the different architectures and how they we kind of fit in these areas responsibility because we all don't use the same things and hopefully you're already kind of thinking about your own systems at home how they would fit into this stuff maybe you're finding some that are crossing these boundaries that are giving you trouble so for evolve Ouiser behaviors we've already kind of talked about this so for our sensing we'll use our sensor manager we have our surrounded sensor maybe any distance sensor things like that for our deciding our behavior trees gonna live there right but if you look the nodes that we're going to be putting in this area are just the ones that help define the structure of the behavior tree right it's our selectors or sequencers and our decorators for acting is basically the rest of our behavior tree notes anything that actually does things right that fire node reload animated attack from navigate to the world States gonna have our blackboard whiteboard if you were to follow the data how it flows through this our sensory manager and retention logic are going to populate things in our world State it also might reference some of that stuff to help to do more sensing our behavior tree is going to pull data from our blackboard in order to make the and on the completion of different nodes and might apply different changes to that life board as well and then when our acting is running our behaviors running is going to pull all the data whether from the black board or the white board in order to make those behaviors work if we're going to do this with an HTM planner very similar a go planner sensing kind of works the same for our designing for HTM domain we'd have a different kind of structure here our compound TAS going to help define the hierarchical structure of our domain while the primitive tasks going to help define the conditions and effects in order to run the acting operations HTN uses operators so the operators are all sitting in our acting side and the dataflow is going to work roughly the same the world state they actually use a world state which is a very simple representation to do their planning Brennen state machines a little trickier basically we'd want to do is have a finite state machine that kind of goes over both sensing and acting and deciding but the states that but we'll have States specifically designed to help the sensing data help collecting that data and then the other states would kind of work like a typical for an state machine now but we want to do with those states is kind of treat those as wrappers to the operator concept that we're going to borrow from the HT and stuff so if you look we have a navigate to enemy state this thing will help to find the transitions to other states and the deedat who supplied to the navigate to operator I still think of world States or great thing to have in a finite state machine that gives you a nice snapshot about every with everything that the AI understands at that point and you can base all your transitions and stuff off this log data anyway so in conclusion modular systems doesn't really quite mean you're making modular characters even though you're using a modular system it may be implementing those modular pieces in a very unmodulated really think in terms of responsibilities when you find something that is a modular I guarantee you've got some sensing and you're deciding or some deciding and your acting crossing that responsibility boundary it's a sure way to shoot yourself in the foot look for the friction in your system and improve it make it easy to do you're sensing work in the right place make it easy to do your starting work in the right place make it easy to do your act and work in the right place you don't need to start a new project and you could do it we were able to do it for the live game while making DLC and we're already seeing the benefits from that this refactor OOP and you can do this thanks a lot to Kevin and Chris Paul they're helping Justin sherry for the art and and my team's thank you [Applause]
